Automatic Eyelet Setting Machine
Automatic Eyelet Setting Machine (Without Washer)
The automatic eyelet setting machine feeds and sets eyelets on fabric, coated fabric, cardboard, leather and similar materials without a separate pre-punching operation. Its automatic feed and laser positioning system supports fast, consistent and efficient production.
- ModelKMS-333-OK
- Capacity50 pcs/min
- Impact Force2 tonnes / 5 mm²
- Throat Depth8 cm
- PowerAC 380 V / 0.25 kW / 1/3 HP
- Net Weight145 kg
- Dimensions142 × 90 × 60 cm
For information about this machine:
+90 212 691 11 31 • kms@kilicoglumakina.com.tr
+90 212 691 11 31 • kms@kilicoglumakina.com.tr
The automatic eyelet setting machine feeds and sets eyelets on fabric, coated fabric, cardboard, leather and similar materials without a separate pre-punching operation. Its automatic feed and laser positioning system supports fast, consistent and efficient production.
Key Features
- Single-motor operation
- Up to 20,000 cycles per 8-hour shift
- Designed for continuous 24-hour operation
- Adjustable setting height
- Configurable for different eyelet sizes
- Reduced cycle time per workpiece
- Up to 99% operating efficiency
- Laser marking of the setting point
- Washer-eyelet capability with the appropriate tooling
